P4 Self-Adhesive Flexible Transparent LED Display for Glass
Its 4 mm pixel pitch is an option to assess when finer image detail matters within a limited window area. Share your glass dimensions, viewing distance and daylight conditions so we can recommend a module layout and prepare a project-specific quotation.
Pixel Pitch: 4mm
Module Size: 1000mm×240mm
Cabinet Size: Customizable
Pixel Density: 62500pixels/m²
Brightness: 4000cd/m²
Refresh Rate: 3840Hz
Color：Full Color
Waterproof：IP30
Life Span： 100000 hours
Warranty： 6 years
Certificate：CE,FCC,ROHS,UL,PSE
Supplier Type：Original manufacturer, OEM,ODM
Media Available：Datasheet, Photo, EDA/CAD Models, Other
Product parameters
| Pixel Pitch(mm) | 4 | |||
| LED Type | SMD1010 | |||
| Pixel Density(pixles/m²) | 62500 | |||
| Brightness(cd/m²) | 3500 | |||
| Permeability | 85% | |||
| Refresh Rate (Hz) | ≥3840HZ | |||
| Weight (lb/cabinet) | 3.5KG | |||
| Cabinet Size (mm) | Customizable | |||
| Module Size (mm) | 1000mm*240mm | |||
| Horizontal/Vertical Viewing Angle | ≥140°/≥140° | |||
| Gray Scale | 16 | |||
| Protection Level | IP30 | |||
| Colour Temp | 3200-8500K | |||
| Input Signal | HDMI, DVI/VGA.RGBHV Composite, S- VIDEO,YPbPr(HDTV)etc... | |||
| Max Power Consumption(W/m²) | 600 | |||
| Avg.Power Consumption(W/m²) | 200 | |||
Product Features
Evaluate Detail at Your Viewing Distance
A smaller pixel pitch provides more pixels within the same area, but the final result also depends on content design, viewing distance and ambient light.
Prepare the Glass for Adhesive Installation
Check the glass surface, coatings, joints and cable access before installation.
Plan the Complete P4 Display
application
fAQ
When should I consider P4 instead of P6 or P8?
Consider P4 when the display area is limited or the content needs finer detail. Compare the same artwork at the intended viewing distance before deciding. Pixel pitch alone does not define a universal minimum viewing distance.
Can the film be applied to every type of glass?
Surface coatings, glass condition and the installation environment can affect suitability. Share the glass specification and site photos so the adhesive and installation method can be confirmed.
What is included in the P4 quotation?
Ask for an itemized scope covering the film modules, controller, power supplies, cables, accessories and any installation services. Freight, taxes and on-site work should be identified separately.
